| Additional Information |
American Bureau Shipping Certificate No. 00-3K50288-X, Lloyd's Register Certificate No. 01/10075, Germanischer Lloyd Certificate No. 57798-91 HH, DET Norske Veritas Certificate No. P-9100 |
| Dimension L (mm) |
62.4 |
| Series |
SV |
| Body Material |
316 Stainless Steel |
| Quality System Certificates |
ISO 9001 Certificate No. GQC 212, ASME Sect II (MO) Certificate No. QSC 584 |
| Dimension L₁ (mm) |
31.2 |
| Dimension E (mm) |
11.2 |
| Dimension H (mm) |
51.00 |
| Dimension C (mm) |
39.80 |
| Flow Coefficient (Cv) |
0.37 |
| Pressure Rating (psi) |
1000, 2000, 3000, 4000, 5000 |
| Pressure Rating (bar) |
344, 69, 138, 206, 275 |
| Temperature Rating (ºF) |
-65 to 450, -65 to 600 |
| Temperature Rating (ºC) |
54 to 232, -54 to 316 |
| Packing Material |
PTFE (Standard)|PEEK |
| Stem Tip |
Vee (Standard), Soft Seat With Kel - F |
| Dimension F (mm) |
45.0 |
| Inlet End Connection |
1/4" Hy-Lok |
| Orifice (mm) |
4.30 |
| Outlet End Connection |
1/4" Hy-Lok |
| Body Pattern |
Straight Pattern (Standard), Angle Pattern |
| Handle |
Black Phenolic Knob, Black Aluminum Bar, Stainless Steel Bar (Standard) |
| Sour Gas |
Without (Standard), NACE MR-01-75 |
| Dimension L₂ (mm) |
31.20 |
| Dimension C1 (mm) |
28.70 |
| Panel Mount |
Without (Standard), With Panel Mount |
| Dimension C2 (mm) |
29.70 |
