CVH3-V-12-S316 700H Series High Pressure Compact Check Valves

Model: CVH3-V-12-S316

Request Quote Quantity

Product Details

Dimension L (mm) 96.00
Body Material 316 Stainless Steel
Pressure Rating (psi) 1000, 2000, 3000, 4000, 5000, 6000
Pressure Rating (bar) 69, 138, 207, 276, 345, 414
Temperature Rating (ºF) -10 to 375
Temperature Rating (ºC) -23 to 190
End Connection Both Metal Gasket Face Seal Fittings
Inlet End Connection 3/4" Metal Gasket Seal
Outlet End Connection 3/4" Metal Gasket Seal
Nominal Cracking Pressure (psig) 1/3, 1, 5, 10, 25
O-Ring Material Ethylene Propylene, Viton : Standard, NBR
Dimension H1 (Body Hex) (mm) 41.30
Flow Dia. (mm) 15.00
Max. Cv 4.70
Nominal Cracking Pressure (bar) 0.02, 0.06, 0.34, 068, 1.7
SS316 Pressure Rating (psig) 3,000
SS316 Pressure Rating (bar) 206
Working Pressure and Back Pressure at 70ºF(20ºC) (psig) 5,000
Working Pressure and Back Pressure at 70ºF(20ºC) (bar) 344
Documentation
PDF 700-Series.pdf
